我司是ALPS授权代理商，ALPS系列产品均有在售，需要了解价格、包装数，交期以及产品资料请咨询在线客服！
|
产品编号 |
照片 |
行程 |
操作部方向 |
电路数 |
接点数 |
动作力 |
切换时限 |
焊接方法 |
操作 |
框脚形状 |
定位销 |
尺寸(W×D×H) |
|
SSAG130100 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Left-side recoil |
For PC board insert |
Without |
3.0×9.05×1.15mm |
|
SSAG130200 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Left-side recoil |
For PC board insert |
With |
3.0×9.05×1.15mm |
|
SSAG130300 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Left-side recoil |
Flat |
Without |
3.0×9.05×1.15mm |
|
SSAG130400 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Left-side recoil |
Flat |
With |
3.0×9.05×1.15mm |
|
SSAG230100 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Right-side recoil |
For PC board insert |
Without |
3.0×9.05×1.15mm |
|
SSAG230200 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Right-side recoil |
For PC board insert |
With |
3.0×9.05×1.15mm |
|
SSAG230300 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Right-side recoil |
Flat |
Without |
3.0×9.05×1.15mm |
|
SSAG230400 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side), 1.5N (Lock side) |
Not specified |
Reflow |
Right-side recoil |
Flat |
With |
3.0×9.05×1.15mm |
|
SSAG330100 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side) |
Not specified |
Reflow |
Double-side recoil |
For PC board insert |
Without |
3.0×9.05×1.15mm |
|
SSAG330200 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side) |
Not specified |
Reflow |
Double-side recoil |
For PC board insert |
With |
3.0×9.05×1.15mm |
|
SSAG330300 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side) |
Not specified |
Reflow |
Double-side recoil |
Flat |
Without |
3.0×9.05×1.15mm |
|
SSAG330400 |
 |
1.5mm |
Horizontal |
1 |
3 |
1N (Recoil side) |
Not specified |
Reflow |
Double-side recoil |
Flat |
With |
3.0×9.05×1.15mm |
SSAG系列用途：
mobiles:智能手机 平板电脑, 头戴式耳机 可穿戴的, 笔记本电脑&周边设备
Energy / Industrial:机器人 无人机, 工业设备, 转换器
Game:家庭用便携设备, VR AR
Healthcare:健康器具, 介护器具, 分析 检查器具
